Huawei SUN2000-100KTL Series User Manual

No. Cable Category Conductor
Cross-Sectional
Area Range
Outer
Diameter
Source
5 AC output
power cable
(multi-core)
● If you connect a PE
cable to the ground
point on the enclosure
and the neutral wire is
not used, you are
advised to use a
three-core (L1, L2, and
L3) outdoor cable and
M12 OT/DT terminals
(L1, L2, and L3).
● If you connect a PE
cable to the ground
point in the
maintenance
compartment and the
neutral wire is not
used, you are advised
to use a four-core (L1,
L2, L3, and PE)
outdoor cable, M12
OT/DT terminals (L1,
L2, and L3), and M10
OT/DT terminals (PE).
● If you connect a PE
cable to the ground
point on the enclosure
and the neutral wire is
used, you are advised
to use a four-core (L1,
L2, L3, and N) outdoor
cable and M12 OT/DT
terminals (L1, L2, L3,
and N).
● If you connect a PE
cable to the ground
point in the
maintenance
compartment and the
neutral wire is used,
you are advised to use
a
ve-core (L1, L2, L3,
N, and PE) outdoor
cable, M12 OT/DT
terminals (L1, L2, L3,
and N), and M10
OT/DT terminals (PE).
● Copper cable:
– S: 70–240
mm
2
– S
p
≥ S/2
● Aluminum
alloy cable or
copper-clad
aluminum
cable:
– S: 95–240
mm
2
– S
p
≥ S/2
24–66 mm Prepared
by the
customer
SUN2000-(100KTL, 110KTL, 125KTL) Series
User Manual 5 Electrical Connections
Issue 07 (2020-09-15) Copyright © Huawei Technologies Co., Ltd. 48
