3
Level
2. (Optional) Install the screw for locking the DC switch.
•
M6x60 expansion bolts are delivered with the solar inverter. If the length and number of the
bolts do not meet installation requirements, prepare M6 stainless steel expansion bolts by
yourself.
•
The expansion bolts delivered with the solar inverter are mainly used for solid concrete walls.
For other types of walls, prepare bolts by yourself and ensure that the wall meets the load
bearing requirements of the solar inverter.
•
In residential areas, do not install the solar inverter on drywalls or walls made of similar
materials which have a weak sound insulation performance because the noise generated by
the solar inverter is noticeable.
•
Loosen the nut, flat washer, and spring washer of the expansion bolt at the bottom.
3. Install the solar inverter onto the mounting bracket.
4. (Optional) Install an anti-theft lock.
Prepare an anti-theft lock by yourself. The lock should be suitable for the lock hole diameter
(Ф10 mm) so that it can be installed successfully. An outdoor waterproof lock is recommended.

Huawei SUN2000 3,6KTL-L1 Specifications

General

Max. efficiency	98.4%
Dimensions (W x H x D)	365 x 365 x 156 mm
Operating temperature range	-25°C to +60°C
IP rating	IP65
Topology	Transformerless
Nominal AC voltage	230 V
Max. input voltage	600 V
Max. input current per MPPT	11 A
Number of MPP trackers	2
Max. short-circuit current per MPPT	15 A
Cooling	Natural convection
Maximum Input Current	22 A
Rated AC power	3600 W
Max. apparent power	3600 VA
Communication interfaces	RS485
MPP voltage range	90 V - 560 V
Maximum Output Power	3600 W
MPPT Voltage Range	90 V to 560 V
