Huawei SUN2000 3,6KTL-L1 User Manual

7
•
For details about how to operate the WLAN-FE Smart Dongle SDongleA-05, see SDongleA-
05 Smart Dongle Quick Guide (WLAN-FE) .
•
For details about how to operate the 4G Smart Dongle SDongleA-03, see SDongleA-03
Quick Guide (4G) .
•
The quick guide is delivered with the Smart Dongle. You can download them by scanning
the QR code below.
WLAN-FE
4G
• Install the SIM card in the arrow direction.
• When reinstalling the cover of the Smart Dongle, ensure that the buckle springs back in
place (you can hear a click).
•
If your Smart Dongle is configured with a SIM card, you do not need to install the SIM card.
The configured SIM card can be used only on the Smart Dongle.
•
If your Smart Dongle is not equipped with a SIM card, prepare a standard SIM card (size: 25
mm x 15 mm) with the capacity greater than or equal to 64 KB.
(Optional) 4G Smart Dongle (4G Communication)
Installing the AC Output Power Cable
3.4
Ensure that the protective layer of the AC output power cable is inside the connector, that the
core wires are totally inserted into the cable hole, and that the cable is connected securely.
Failing to do so may cause device malfunction or damage.

Huawei SUN2000 3,6KTL-L1 Specifications

General

Max. efficiency	98.4%
Dimensions (W x H x D)	365 x 365 x 156 mm
Operating temperature range	-25°C to +60°C
IP rating	IP65
Topology	Transformerless
Nominal AC voltage	230 V
Max. input voltage	600 V
Max. input current per MPPT	11 A
Number of MPP trackers	2
Max. short-circuit current per MPPT	15 A
Cooling	Natural convection
Maximum Input Current	22 A
Rated AC power	3600 W
Max. apparent power	3600 VA
Communication interfaces	RS485
MPP voltage range	90 V - 560 V
Maximum Output Power	3600 W
MPPT Voltage Range	90 V to 560 V
