● Stay away from the equipment when preparing cables to prevent cable scraps
from entering the equipment. Cable scraps may cause sparks and result in
personal injury and equipment damage.
● When routing PV cables whose pipe is less than 1.5 m long, the positive and
negative PV string cables shall be routed in dierent pipes to prevent cable
damage and short circuits caused by improper operations during construction.
The cable colors shown in the electrical connection diagrams provided in this section are for
reference only. Select cables in accordance with local cable specications (green-and-yellow
cables are only used for protective earthing).
5.2 Crimping the OT Terminal
Requirements for the OT Terminal
● If a copper cable is used, use a copper wiring terminal.
● If a copper-clad aluminum cable is used, use a copper wiring terminal.
● If an aluminum alloy cable is used, use a copper to aluminum adapter
terminal or an aluminum wiring terminal with a copper to aluminum adapter
washer.
● Directly connecting an aluminum wiring terminal to the AC terminal block will
cause electro-chemical corrosion and weaken the cable connection reliability.
● The copper to aluminum adapter terminal or an aluminum wiring terminal
with a copper to aluminum adapter washer must comply with IEC61238-1.
● Do not mix up the aluminum and copper sides of the copper to aluminum
adapter washer. Ensure that the aluminum side of the washer contacts the
aluminum wiring terminal, and the copper side contacts the AC terminal block.
SUN2000-(50KTL, 60KTL, 65KTL)-M0
User Manual 5 Electrical Connections
Issue 11 (2024-02-02) Copyright © Huawei Technologies Co., Ltd. 42
