8
Other Installation Options
Purchase a tripod and install the TE30 on it. The tripod must be able to bear a weight of at least
10.5 kg (23.15 lb), and the sizes and positions of its holes must be the same as those of the holes
on the bottom of the TE30.
Connecting Cables
The following figure shows a cable connection example in which the HDMI port is used for
video output.
The VGA cable is not provided with the TE30. You need to purchase it by yourself.
The cable connection shown in the preceding figure is the simplest and provided only for reference. For the cable
connection instructions on the Huawei microphone array and VPC camera that come with the TE30, visit
http://enterprise.huawei.com and choose SUPPORT > Product Support > Unified Communications and
Collaboration > Telepresence and Videoconferencing > Telepresence Endpoints > Group Endpoints > TE30.
