Huawei Telecom Power TP48120A-HD15A1 User Manual

TP48120A-HD15A1, TP48120A-HD15A2,
TP48200A-HD15A1, and TP48200A-HD15A2 Telecom
Power
User Manual
3 Components
Issue 03 (2020-01-04)
Copyright © Huawei Technologies Co., Ltd.
28
3.2.1 Battery Switch
Figure 3-5 Battery switch
(1) Battery switch

Before delivery, the battery switch is set to AUTO and the system is under automatic
control.

Open the panel and flip the battery switch to MANUAL only when you need to forcibly
power on batteries. Flip the battery switch back to AUTO after the commissioning.
3.3 Rectifier
Rectifiers convert AC input into stable DC output.
Figure 3-6 Rectifier
(1) Power indicator
(2) Alarm indicator
(3) Fault indicator
(4) Locking latch
(5) Handle
Table 3-2 Rectifier indicators
Indicator
Color
Status
Description
Power indicator
Green
Steady on
The rectifier has an AC power input.
