C Associations between Alarms and the Dry Contacts on
the UIM
Issue 03 (2020-01-04)
Copyright © Huawei Technologies Co., Ltd.
73
C Associations between Alarms and the
Dry Contacts on the UIM
Table C-1 Associations between alarms and dry contacts
Port Type
Silk Screen
Associated Alarm
Dry Contact input port
DIN1
Dry Contact input 1
DIN2
Dry Contact input 2
DIN3
Dry Contact input 3
DIN4
Dry Contact input 4
DIN5
Dry Contact input 5
DIN6
Dry Contact input 6
Dry Contact output
port
(closed: alarm; open:
normal) can be
modified by
customers.
ALM1
AC power failure alarm
ALM2
DC overvoltage or undervoltage alarm
ALM3
Rectifier fault alarm
ALM4
AC or DC SPD fault alarm
ALM5
Battery or load fuse blown alarm
ALM6
Battery overtemperature or undertemperature alarm
ALM7
Door status alarm
ALM8
Fan, air conditioner, or heater fault alarm
