Huawei Telecom Power TP48120A-HD15A1 User Manual

TP48120A-HD15A1, TP48120A-HD15A2,
TP48200A-HD15A1, and TP48200A-HD15A2 Telecom
Power
User Manual
A Technical Specifications
Issue 03 (2020-01-04)
Copyright © Huawei Technologies Co., Ltd.
70
Table A-3 EMC specifications
Item
Specifications
Electromagnetic
interference (EMI)
Conducted emission (CE)
Class A, EN300386
Radiated emission (RE)
Class A, EN300386
Harmonic
EN61000-3-12
Fluctuation and flick
EN61000-3-11
Electromagnetic
susceptibility (EMS)
Electrostatic discharge (ESD)
EN61000-4-2
Contact discharge: 6 kV (criterion B); air
discharge: 8 kV (criterion B)
Electrical fast transient (EFT)
IEC61000-4-4
Signal port: ±1 kV (criterion B); AC power port:
±2 kV (criterion B); DC power port: 2 kV
(criterion B)
Radiated susceptibility (RS)
EN61000-4-3
Field strength: 10 V/m (criterion A)
Conducted susceptibility (CS)
EN61000-4-6
Power port: 10 V; signal port: 3 V (criterion A)
Surge immunity
IEC61000-4-5
AC and DC power ports: differential mode: ±2
kV (criterion B); common mode: ±4 kV
(criterion B). Signal port: differential mode: 0.5
kV (criterion B); common mode: 1 kV (criterion
B)
Voltage dips (DIP)
EN61000-4-11
Table A-4 Cabinet specifications
Item
Specifications
Dimensions (H x W x D)
1500 mm x 650 mm x 650 mm (excluding the base and the
protruding part of the door)
Base dimensions (H x W x D)
100 mm x 650 mm x 650 mm
Weight
< 120 kg (excluding rectifiers and batteries)
Protection level

Equipment compartment: IP55

Battery compartment: IP44
Installation mode
On a floor
Maintenance mode
Operated and maintained from the front
Cable routing
Routed in and out from the bottom
