Inquiry Commands (Continued) .
Inquiry Command
Command Packet
Inquiry Packet
Comments
CAM_VersionInq
8x 09 00 02 FF
y0 50 00 01
mn pq rs tu vw FF
mnpq: Model Code (0504)
rstu: ROM version
vw: Socket Number (=02)
Information Display
8x 09 7E 01 18 FF
y0 50 02 FF
On
y0 50 03 FF
Off
VideoSystemInq
8x 09 06 23 FF
y0 50 00 FF
1920 x1080i/60
60 Hz system
y0 50 01 FF
1920 x1080p/30
y0 50 02 FF
1280 x720p/60
y0 50 03 FF
1280 x720p/30
y0 50 07 FF
1920 x1080p/60
y0 50 08 FF
1920 x1080i/50
50 Hz system
y0 50 09 FF
1920 x1080p/25
y0 50 0A FF
1280 x720p/50
y0 50 0B FF
1280 x 720p/25
y0 50 0F FF
1920 x1080p/50
IR_Receive
8x 09 06 08 FF
y0 50 02 FF
On
y0 50 03 FF
Off
Pan-tiltMaxSpeedInq
8x 09 06 11 FF
y0 50 ww zz FF
ww = Pan Max Speed
zz = Tilt Max Speed
Pan-tiltPosInq
8x 09 06 12 FF
y0 50 0w 0w 0w 0w
0z 0z 0z 0z FF
wwww = Pan Position
zzzz = Tilt Position
Pan-tiltModeInq
8x 09 06 10 FF
y0 50 pq rs FF
pqrs: Pan/Tilt Status
CAM_AnalyticsInq
8x 01 0E 24 6E 00 00 FF
[tracking status on/off][current X,
Y, Z][#][human][date powered
on][date command was sent]
Inquires tracking status, current PTZ
position, faces in sight, & when the
command was sent
