5.
INSTALLATION
You must install the battery first and then Tip properly as the following instructions before use the device.
5-1. Installing the battery and Tip (Including the Front Cap)
1.
Open the battery cover and insert a battery into the socket at the end of the main body.
To remove a battery, open the battery cover and gently pull out the battery from the socket.
2.
Detach the Front Cap from the front of the main body.
3.
Move the slide bar forward until it doesn’t move any more.
[Note]
When the front cap and tip are removed, the laser is emitted from where the tip was connected.
If only the front cap is mounted without the tip, the laser is emitted through the front cap
from where the tip was connected.
17
