19
Troubleshooting
Error Solution
Table does not
move
Ensure all cords are fully secured and the outlet your table is plugged into has
power�
Table moves at a
slow rate
Reset table�
Hand Switch
Error Codes:
E01 - E08
Ensure all cables are fully secured� Follow the steps to Reset your table� If you
are still encountering an error please call customer care�
Technical Data
Two Column Kit Two Column Kit, Beamless
Power supply 120VAC 50/60Hz
Maximum input current 4�2A
Stand by power consumption, primarily <0�1W
Operating Temperature 5 - 40
O
C
Height Range (Standard Range) 26�8” - 46”
Height Range (Extended Stage) 21�5” - 47�6”
Base Width 42” - 72”
Can not exceed 54" from
the outside of the columns�
Travel Speed 1” per second (no load)
Noise Level <50dB
Maximum lift capacity
(Including worksurface)
250lbs
Duty Cycle 10% Max� 2 min on, 18 mins off
