Page #510 background image
Fuses Usage
PARK LP Parking Lamps Relay
STRTR Starter Relay
INTPARK Roof Marker Lamps
STOP LP Stoplamps
TBC BATT
Truck Body Controller
Battery Feed
SEO B2 Off-Road Lamps
4WS Not Used
AUX PWR
Instrument Panel Outlets,
Rear Cargo Area Power
Outlets, Console
PCM 1 Powertrain Control Module
ETC/ECM
Electronic Throttle Control,
Electronic Brake Controller
IGN E
Instrument Panel Cluster,
Air Conditioning Relay, Turn
Signal/Hazard Switch, Starter
Relay, Electronic Brake
Controller TC2 Mode Switch
RTD
Electronic Brake Controller
Battery Feed
Fuses Usage
TRL B/U Backup Lamps Trailer Wiring
F/PMP Fuel Pump (Relay)
B/U LP
Back-up Lamps, Automatic
Transmission Shift Lock
Control System
RR DEFOG Rear Window Defogger
HDLP-HI Headlamp High Beam Relay
PRIME Not Used
AIRBAG
Supplemental Inflatable
Restraint System
FRT PARK
Front Parking Lamps,
Sidemarker Lamps
DRL
Daytime Running Lamps
(Relay)
SEO IGN Rear Defog Relay
TBC IGN1 Truck Body Controller Ignition
HI HDLP-LT
Driver’s Side High Beam
Headlamp
LH HID Not Used
DRL Daytime Running Lamps
510
