Center Roof Marker Lamps
To replace one of these bulbs, do the following:
1. Push in on the notch with a flat tool and pull
the lamp out.
2. Turn the bulb socket counterclockwise and
remove it from the lamp housing.
3. Remove the bulb from the bulb socket.
4. Install a new bulb into the bulb socket.
5. Place the hook end of the lamp in place on
one side and push the other end of the lamp
down until it locks in place.
Taillamps, Turn Signal, Stoplamps
and Back-up Lamps
A. Stoplamp/Taillamp
B. Turn Signal Lamp
C. Back-Up Lamp
To replace one of these bulbs, do the following:
1. Open the liftgate or tailgate. See Liftgate
(SUV) on page 104 or Tailgate/Spare Tire
Carrier on page 108 for more information.
444
