19
ATTACHING THE THERMOSTAT
Lift the thermostat cover and set the SYSTEM to OFF
and the FAN switch to AUTO.
1. Locate the HE/HG on the back of the thermostat. Set
the switch to HG (default) for gas furnace and oil burners.
Set the switch to HE for electric furnaces.
(The switch has no eect when the system is set to cooling
mode.)
2. Locate the Auto Recovery switch on the back of the
thermostat. If you wish to use the Auto Recovery feature,
verify that the switch is in the ENABLE position. If you do
not wish to use this feature, simply change the switch
to the DISABLE position. See pages 44-45 for more
information.
3. System type - Locate the
switch on the
back of the thermostat. Select either STD (Standard) or
HP (Heat Pump) to match your system.
INSTALLING THE THERMOSTAT, CONT.
