25
Maximum Distance Between Controller/Sensor Decoder and Sensor: 1000 ft/300 m
Wire: 18 AWG/1 mm, 36”/1 m leads (Ø = diameter)
Dimensions
FCT Tee Fitting Height Width Length
Straight Pipe
upstream (Ø x 10)
Straight Pipe
downstream (Ø x 5)
FCT 100 4.8″/12 cm 2.3"/6 cm 4.5"/11 cm 10"/25 cm 5"/13 cm
FCT 150 5.4″/14 cm 2.3"/6 cm 4.6"/12 cm 15"/38 cm 8"/20 cm
FCT 158 5.4″/14 cm 2.3"/6 cm 5.1"/13 cm
FCT 200 6″/15 cm 2.7"/7 cm 4.7"/14 cm 20"/50 cm 10"/25 cm
FCT 208 6″/15 cm 2.7"/7 cm 5.4"/14 cm
FCT 300 7″/18 cm 4"/10 cm 6.2"/16 cm 30"/76 cm 15"/38 cm
FCT 308 7″/18 cm 4.2"/11 cm 6.4"/16 cm
FCT 400 8″/20 cm 5"/13 cm 6.2"/16 cm 40"/1 m 20"/50 cm
