Hunter ST Series User Manual

11
hunter industries.com
ST1600 SHORTRADIUS NOZZLE KIT PERFORMANCE CHART  P/N 959900
Nozzle Pressure Radius Flow Precipitation in/hr
PSI  GPM
8 60 70 23.3 0.92 1.06
70 72 25.5 0.95 1.09
90 74 27. 3 0.96 1.11
100 76 29.2 0.97 1.12
10 60 81 37.8 1.11 1.28
70 84 42.5 1.16 1.34
90 86 47.1 1.23 1.42
100 88 51.0 1.27 1.46
12 60 92 53.9 1.23 1.42
70 94 60.5 1.32 1.52
90 96 65.7 1.37 1.58
100 98 71.8 1.44 1.66
14 60 103 69.3 1.26 1.45
70 105 78.2 1.37 1.58
90 108 85.5 1.41 1.63
100 110 92.5 1.47 1.70
Important
The water may contain foreign objects
such as sand, rocks, and other impurities,
which can damage the rotor. To avoid
these problems, you may need to install
a lter.
Aer Installation
Troubleshooting non-rotation aer
installation:
1. Check for plugged secondary nozzle.
2. Check for a blocked propeller in the
turbine assembly.
hunter.help/ST1600Support
1-760-591-7383
Find other helpful information about your product, including installation tips and more.
Caution
• Stand clear of the rotor's water jet and
area of operation.
• Ensure the water jet is not directed
toward persons, animals, power lines,
roads, or other objects.
Troubleshooting

Hunter ST Series Specifications

General

Arc Adjustment	40-360 degrees
Operating Pressure	30-70 PSI
Inlet Size	1/2 inch
Pop-up Height	4 inches
Material	Plastic
