Hunter ST Series

2
Installation
• With a maximum radius of 165',
the ST-1600 Rotor is designed for
placement outside the eld for safety
and serviceability.
• Pair the rotor with the ST-1600-KIT
vault system to bring all irrigation
components together inside one
strong enclosure for simple access
to the complete system.
ST-1600-HS-B: Pop-Up Gear Drive
The best-in-class gear-driven ST-1600-HS-B Synthetic Turf Rotor oers a premium solution for
synthetic turf irrigation. The rotor cools, cleans, and ushes synthetic sports elds to enhance eld
safety and playability. With a throwing radius up to 165', the powerful and reliable ST-1600-HS-B
Rotor oers years of solid performance in a range of applications.
ST-1600-HS-BR: Riser-Mounted Gear Drive
The riser-mounted ST-1600-HS-BR conguration is an ideal retrot option for synthetic turf
irrigation. It is also an eective dust-control solution for horse arenas, corrals, and pastures.
Key Benets
• Heavy-duty internal gear drive and
stainless steel pop-up riser provide
years of reliable operation
• Long-range performance exibility up
to 165' with six nozzle choices
• Full-circle and adjustable arc in one
model from 40° to 360°
• Adjustable speed of rotation using the
adjustment knob to set the speed to
your requirements
Factory Settings
• Preinstalled #20 nozzle; other nozzles
are included in the packaging
• Speed control pre-set for maximum
speed of rotation
• 40° arc setting
Table of Contents
2 Overview
3 Product Details
4 ST-1600-HS-B Replacement Parts
5 Servicing and Maintenance
6 ST-600-KIT System Components
7 Riser-MountedSystem Components
8 Field Layouts
11 Troubleshooting
Overview
