12 – English
Service data
436LiB: S/N XXXXXXXXX-, 536LiB: S/N YYYYYYYYY-, 536LiBX: S/N ZZZZZZZZ-
Service data
Key
The numbers by bolted components represent the tightening torque in Nm.
Lubricate with water resistant grease.
(x3) 2,8 Nm
(x2) 1 Nm
4 mm
(x3) 1,9 Nm
4 mm
(x3) 1,6 Nm
4 mm
(x2) 1 Nm
(x3) 1.6 Nm
4 mm
(x3) 2.8 Nm 4 mm
(x3) 1.9 Nm 4 mm
