English – 29
Fig 26b
Repair instructions
5
(436LiB, 56LiB)
Unhook all the cables from their attachments and
lift the control unit, main switch and main cables
straight out of the chassis.
NB! Do not pull the wires.
See gure 26a (436LiB, 536LiB).
(536LiBX)
Unhook all the cables from their attachments
and uncouple the connector on the signal cables.
Remove the connector from the control card with a
screwdriver, see gure 32, and lift the cables out of
the chassis. Insert the cables through the display
cover.
NB! Do not pull the wires.
See gure 26b (536LiBX).
Fig 26a
