Husqvarna 701 Enduro 2018 User Manual

BRAKE SYSTEM 13
151
13.8 Checking the free travel of foot brake lever
Warning
Danger of accidents The brake system fails in the event of overheating.
If there is no free travel on the foot brake lever, pressure builds up in the brake system on the rear
brake.
– Set the free travel on the foot brake lever in accordance with the specification.
402027-10
– Move the foot brake lever back and forth between the end
stop and the contact to the foot brake cylinder piston and
check free travel
A
.
Guideline
Free travel at foot brake
lever
3 … 5 mm (0.12 … 0.2 in)
Info
You will know that contact has been made with the
foot brake cylinder piston when there is increased
resistance when you activate the foot brake lever.
» If the free travel does not meet specifications:
– Adjust the basic position of the foot brake lever.
( p. 152)

Husqvarna 701 Enduro 2018 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	692.7 cc
Bore x Stroke	105 mm x 80 mm
Compression Ratio	12.6:1
Starter	Electric
Transmission	6-speed
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	140/80-18
Power	74 hp (55 kW) @ 7, 500 rpm
Fuel System	Fuel injection
Front Suspension	WP USD, 48 mm
Rear Suspension	WP monoshock
Front Brake	300 mm disc
Rear Brake	Brembo 240 mm disc
ABS	Yes, switchable
Ground Clearance	270 mm
Fuel Capacity	13 liters (approx. 3.4 gallons)
Dry Weight	145 kg
