INTRODUCTION AND SECURITY
Moving Around
The original packaging should be used when transporting
the robotic lawnmower over long distances.
To safely move from or within the working area:
1. Press the STOP button to stop the robotic
lawnmower. If security is set to the medium or
high level (see 6.5 Security on page 47.), the
PIN code has then to be entered. The PIN code
contains four digits and is selected when you start
the robotic lawnmower for the rst time, see 3.8
First Start-up and Calibration on page 32.
2. Set the main switch in 0 position.
3. Carry the robotic lawnmower by the handle
found at the rear of the product. Carry the robotic
lawnmower with the blade disc away from the
body.
IMPORTANT INFORMATION
Do not lift the robotic lawnmower when
it is parked in the charging station. It can
damage the charging station and/or the ro-
botic lawnmower. Press STOP and instead
rst pull the robotic lawnmower out of the
charging station before lifting it.
1157866-26,420,430X,450X,EN_160314.indd 8 2016-03-14 16:58:13

Husqvarna AUTOMOWER 430X Specifications

General

Product Name	Husqvarna AUTOMOWER 430X
Category	Lawn Mower
Cutting Width	24 cm
Cutting Height Min	20 mm
Cutting Height Max	60 mm
Battery Type	Li-ion
Typical Charging Time	50 min
Maximum Incline Within the Working Area	45 %
Cutting System	3 pivoting razor blades
GPS-assisted Navigation	Yes
Lift Sensor	Yes
Tilt Sensor	Yes
Ultrasonic Sensor	No
Battery Voltage	18 V
Weight	13.2 kg
Connectivity	Bluetooth, Cellular
Weather Resistance	Yes
Warranty	2 years
