3012-1040
3012-1041
3012-1352
3012-221
English - 10
PRESENTATION
2 Presentation
This chapter contains information that is important to be
aware of when planning the installation.
Installing a Husqvarna robotic lawnmower involves four
main components:
• A robotic lawnmower that mows the lawn by
essentially operating in a random pattern. The robotic
lawnmower is powered by a maintenance-free battery.
• A charging station, to where the robotic lawnmower
returns when the charge level in the battery becomes
too low.
The charging station has three functions :
• To send control signals along the boundary wire.
• To send control signals along the guide wires.
• To charge the battery in the robotic lawnmower.
• The power supply, which is connected between the
charging station and a 100V-230V wall socket. The
power supply is connected to the wall socket and to
the charging station using a 10 m long low voltage
cable. The low voltage cable must not be shortened
or extended.
A longer low voltage cable is available as optional
accessory. Contact your local dealer for more
information.
• A search wire, laid in a loop around the robotic
lawnmower’s working area. The loop wire is laid
around the edges of the lawn and around objects and
plants that the robotic lawnmower must not run into.
The loop wire is also used as the guide wire.
The maximum permitted length for the boundary loop
is 800 m.
IMPORTANT INFORMATION
Search wires, pegs, couplers and connec-
tors are available in a separate installation
kit.
Always use original spare parts
1157866-26,420,430X,450X,EN_160314.indd 10 2016-03-14 16:58:16
