8 Technical data
8.1 Technical data
Dimensions Automower
®
435X AWD
Length, cm / in. 93 / 36.6
Width, cm / in. 55 / 21.6
Height, cm / in. 29 / 11.4
Weight, kg / lbs 17.3 / 38.1
Electrical system Automower
®
435X AWD
Battery, Lithium-Ion 18 V/5.0 Ah Art. No. 590 81 01-01
Battery, Lithium-Ion 18 V/4.9 Ah Art. No. 590 81 01-02
Power supply, V/28 V DC 100-240
Low voltage cable length, m / ft 10 / 33
Mean energy consumption at maximum use 24 kWh/month in a 3500 m
2
Charge current, A DC 7
Typical mowing time, min 100
Typical charging time, min 30
Boundary wire antenna Automower
®
435X AWD
Operating Frequency Band, Hz 300-80000
Maximum Radio-frequency power, mW @60m
6
<25
Noise emissions measured in the environment as sound
power
7
Automower
®
435X AWD
Measured sound power noise level, dB (A) 60
Guaranteed sound power noise level, dB (A) 62
Sound pressure noise level at the operator’s ear, dB (A)
8
49
The noise emission declarations conforms to EN 50636-2-107:2015
6
Maximum active output power to antennas in the frequency band in which the radio equipment
operates.
7
Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC di-
rective 2000/14/EC and New South Wales legislation (Protection of the Environment Operations
Regulation 2017, Noise Control). The guaranteed sound power level includes variation in pro-
duction as well as variation from the test code with 1-3 dB(A).
8
Sound pressure noise uncertainties K
pA
, 2-4 dB (A)
62 - Technical data 1404 - 002 -
