Husqvarna TC 50 2017 User Manual

11 SERVICE WORK ON THE CHASSIS 38
11.14 Removing the start number plate
S01493-10
–
Remove screw

.
– Detach and remove the start number plate.
11.15 Installing the start number plate
S01494-10
– Attach the start number plate.
– Position the start number plate.
Holding lugs

engage in the fender.
S01495-10
–
Mount and tighten screw

.
Guideline
Start number plate screw M6 4 Nm (3 lbf ft)
11.16 Dismounting the front fender
S01496-10
–
Remove screws

. Remove the front fender.
11.17 Installing the front fender
S01497-10
– Position start number plate on the fender.
The holding lugs of the start number plate engage in drill holes

of the
fender.
