H.39Part. N. H0368 (09-2008)
ENGINE REASSEMBLY
Reassembly of the gear shift position sensor
Remount the spring and the neutral cap in their seat on the positive shaft.
Reassembly of cylinder head cover, spark plug, lubrication hose
Mount the cylinder head cover and its gasket on the cylinder head. Tight the screws
whilst following a cross-over pattern and in steps (8 Nm-0,8 Kgm-5.8 ft/lb).
Assemble the spark plug (10÷12 Nm-1÷1,23 Kgm-7.2÷8.9 ft/lb) and the lubrication
hose (15 Nm-1,5 Kgm-10.8 ft/lb).
