EN - 44

Fit the wheel axle (2) from the R.H. side, after greasing it and

push it to the stop on the L.H. leg; during this operation, the

wheel should be turned. Tighten the screw (3) on the fork L.H.

side but DO NOT lock it. Now, pump for a while, pushing the

handlebar downwards until you are sure that the fork legs are

perfectly aligned.

Lock: the screws (1) on the R.H. leg (10,4 Nm/ 1,05 Kgm/ 7.7

ft-lb), the screw (3) on the L.H. side (51,45 Nm/ 5,25 Kgm/

38 ft-lb), the screws (1) on the L.H. leg (10,4 Nm/ 1,05 Kgm/

7.7 ft-lb).

REASSEMBLING THE FRONT WHEEL

Fit the L.H. spacer on the wheel hub.

Fit the wheel between the front fork legs so that the brake disc

is fitted into the caliper.

NOTE

After reassembly, pump the brake control lever until the pads

are against the brake disc.
