18
1047356-26
Settings
9.Setting the feed dog in relation to the needle plate
Check
Sideways the feed dog should be symmetrically set in relation to the needle plate slot.
Adjustment
1. Remove the presser foot and holder.
2. Remove the needle plate.
3. Loosen the 2 screws (A) that holds the feed dog.
4. Adjust the feed dog so that the teeth is centered in the needle plate.
5. Retighten the screws (A).
6. Mount the needle plate and presser foot and holder.
AA
