Husqvarna VIKING Designer Jade 20 User Manual

41
1047356-26
G. Top Cover
1. Pull the top cover to left side hinge (a) toward
outside.
2. Pull the top cover to right side hinge (b) toward
outside, remove the top cover.
H. Rear Enclosure
1. Lower the presser foot lifter.
2. Remove the screw cap (c), remove the screw.
3. Pull the rear enclosure backward and remove it.
Covers
1
G
2
a
b
a b
c
