Stretch stitch balance
Check
When a stretch stitch is sewn the forward feeding and backward feeding should be equal when sewing stretch stitch
pattern.
Adjustment
1. Remove the face cover, back cover and front cover.
2. Set pattern selector dial to "D", stitch length dial to "Sl"
3. Put a piece of paper under the presser foot, and turn the hand wheel to check the needle drop position in forward
and backward feeding.
4. Loosen the set screw (a) and adjust the regulator nut (b).
5. If the stitch gap is
- too big (J), turn the regulator nut (b) clock-wise.
- too tight (K), turn the regulator nut (b) counter clock-wise.
6. Attach the covers.
(K)
(J)
