26 104 72 72-26
Buttonhole - the colums, cutting space
Check
The cutting space between columns shall be 0.3 - 0.5 mm.
Adjustment
1. Remove plate (A).
2. Loosen screw (a) then adjust screw nut (b).
3. Make sure cutting space is between 0.3 - 0.5mm. (At this moment, the hairline of the screw nut is positioned where
the arrow pointed.
4. Tighten screw (a) and attach plate (A).
NOTE! This adjustment affect ”The centre position of the needle in straight stitching” adjustment.
