Buttonhole - the colums, feed balance
Check
When sewing a buttonhole, the stitches on each side of the buttonhole should be sewn with the same density.
Adjustment
1. Set stitch length dial to “0.5” to “1.
2. Sew the right side by setting the selector dial at “ “ and then the left side by setting at “ “.
3. Remove circle plate (A).
4. Loosen the 6mm screw nut (a) and adjust screw (b):
If the right row is denser (A), turn the adjusting screw (a) counter-clock-wise.
If the left row is denser (B), turn the adjusting screw (a) clock-wise.
5. After adjustment, tighten screw nut (a).
6. Attach the plate (A).
A B
