Hussmann ISLA Series - Page 42

42
Wiring Diagrams (Cont'd)
DATE:
PROJECT TITLE:
DRAWING #:
DRAWN BY:
PRODUCTION ORDER #:
DRAWING TITLE:
DATE:
Hussmann Corporation, Int'l.
13770 Ramona Avenue
Chino, CA. 91710
(909)-590-4910 Lic.#: 644406
REVISIONS:
#: DESCRIPTION:
CHECKED BY:
BY:
FILE LOCATION:
MATT GRAMTA
PAGE OF

1 3
11/30/11
ISLA HOT
W6600014
IM-03-4-H 208V
RED # 12
BLACK # 12
WHITE # 14
SENSOR
GRN # 14
RED # 14
BLK # 14
RECEPTACLE
1H10042550
PLUG
NEMA 6-15P
SENSOR
GRN # 14
RED # 14
BLK # 14
RECEPTACLE
1H10042550
PLUG
NEMA 6-15P
SENSOR
GRN # 14
RED # 14
BLK # 14
RECEPTACLE
1H10042550
PLUG
NEMA 6-15P
TOP SHELF HEATER #1
3.8A @ 208VAC
1H39636550
TO SENSOR
RECEPTACLE #1
1H40926550
3 LEVEL CONTROL
1H40923550
SHELVES
TAG
ORANGE
FP28/83 T5-48" 125-03-1131
BALLAST 125-01-3267 FULHAM LH4-120-L
BLACK # 14
TO SENSOR
RECEPTACLE #2
1H40926550
TO SENSOR
RECEPTACLE #4
1H40926550
CANOPY
LIGHT CIRCUIT= 0.65A 70W
LIGHT SWITCH
125-01-0307
FP21/830 T5-36" 125-03-1128
BALLAST 125-01-3267 FULHAM LH4-120-L
~208 VAC - 60 HZ
CIRCUIT #1
G
L2
L1
N
GREEN # 10
FP21/830 T5-36" 125-03-1128
TOP SHELF HEATER #2
3.8A @ 208VAC
1H39636550
TOP SHELF HEATER #3
3.8A @ 208VAC
1H39636550
