Hussmann ISLA Series - Page 41

41
Wiring Diagrams (Cont'd)
DATE:
PROJECT TITLE:
DRAWING #:
DRAWN BY:
PRODUCTION ORDER #:
DRAWING TITLE:
DATE:
Hussmann Corporation, Int'l.
13770 Ramona Avenue
Chino, CA. 91710
(909)-590-4910 Lic.#: 644406
REVISIONS:
#: DESCRIPTION:
CHECKED BY:
BY:
FILE LOCATION:
CRAIG BOOREY
PAGE OF

1 3
6/28/12
ISLA HOT
W6600037
IM-03-I3-H 240V
~208VAC - 60 Hz.
CIRCUIT #1
TERMINAL
BLOCK
125-01-0295
RED # 10
GREEN # 10
BLACK # 10
L1
L2
N
G
WHITE # 14
SENSOR
GRN # 14
RED # 14
BLK # 14
RECEPTACLE
1H10042550
PLUG
NEMA 6-15P
SENSOR
GRN # 14
RED # 14
BLK # 14
RECEPTACLE
1H10042550
PLUG
NEMA 6-15P
SENSOR
GRN # 14
RED # 14
BLK # 14
RECEPTACLE
1H10042550
PLUG
NEMA 6-15P
SHELF HEATER #1
2.0A @ 208VAC
2.3A @ 240VAC
1H39635550
TO SENSOR
RECEPTACLE #1
1H40926550
3 LEVEL CONTROL
1H40923550
SHELVES
TAG
ORANGE
F14T5-24" 125-03-1125
BLACK # 14
TO SENSOR
RECEPTACLE #2
1H40926550
TO SENSOR
RECEPTACLE #3
1H40926550
CANOPY
LIGHT CIRCUIT= .39A 42W
LIGHT SWITCH
125-01-0307
15 AMP FUSE
125-01-8604
FUSE HOLDER
125-01-8605
15A
SHELF HEATER #2
2.0A @ 208VAC
2.3A @ 240VAC
1H39635550
SHELF HEATER #3
2.0A @ 208VAC
2.3A @ 240VAC
1H39635550
CAP OFF WIRE
BALLAST 125-01-3267 FULHAM LH4-120-L
BALLAST 125-01-3267 FULHAM LH4-120-L
F14T5-24" 125-03-1125 F14T5-24" 125-03-1125
A CN#634531 6/28/12 CB
B RESET TO REV-B 8/15/12 CB
