17
Model Tier Description Size Diagram #
Entyce TY3
TY3ECRC-5X7I-S 7 ft 3113662
TY3ECRC-3X4.5E-S 4.5 ft 3141053
TY3ECRC-3X5.5E-S 5.5 ft 3138635
TY3ECRC-4X6E-S 6 ft 3140950
Electrical Wiring Diagram Index (Standard Shelf Lights)
Model Tier Description Size Diagram #
Entyce TY3
TY3ECRC-5X7I-S 7 ft XXXXXXX
TY3ECRC-3X4.5E-S 4.5 ft 3145917
TY3ECRC-3X5.5E-S 5.5 ft 3145916
TY3ECRC-4X6E-S 6 ft 3147479
Electrical Wiring Diagram Index (Chain Shelf Lights)
Wiring Diagram Access
A Wiring diagram was shipped with the case and packaged with this Installation Manual. If the
diagram is missing or misplaced, please contact Hussmann (page 4 or 29) for an electronic
version.
Case Parameters and Setpoints
TY3ECRC
Parameter 3X4.5E-S 3X5.5E-S 4X6E-S 5X7I-S
Program PGM0045A03 PGM0045A06 PGM0045A01 PGM0045A04
Type I Setpoint [°F / °C] 23 / -5.0 22 / -5.6 24 / -4.4 24 / -4.4
Type II Setpoint [°F / °C] TBD TBD 23 / -5.0 24 / -4.4
Differential [°F / °C] 8 / 4.5 8 / 4.5 8 / 4.5 12 / 6.4
Defrost Termination Air Temp [°F / °C] 46 / 7.8 48 / 8.9 52 / 11.1 46 / 7.8
Interval Between Defrost Starts [hr] 2 2 4 2
Max Defrost Duration [min] 40 40 50 50
