1. Torque to 23 N•m.
2. Torque to 136 N•m.
3. Torque to 41 N•m.
Item Part No. Qty Name
1 710087 4 CS .312-18X2.500HXG5
2 768523 16 FW 0.343SAE
3 043067 4 CS .312-18X3.000HXG5
4 704791 1 FW .781X1.25X.02 ZN
5 781153 2 BUSHING, UHMW
6 605468 1 DRIVE BELT
7 025007 1 CS .62511X1.750HXG5
8 607525 1 PULLEY, IDLER
9 600296 1 SPACER, DECK IDLER
10 122722 1 KIT, TENSION ARM
11 016972 1 NT .625-11 HX G5 ZN
12 052860 1 CS .375-16X1.25 HX G5 ZN
13 712919 1 FW 0.406X1.00X.12 HD ZN
14 036384 1 SPRING 1/4 COIL PL 1.23
15 605481 1 BUSHING
16 086660 1 NT .375-16NLG8
17 025296 1 FW .760X1.63X0.08 ZN
18 601084 1 SB .750X 2.000 SH.625-11
19 605500 1 ZT3400, 21.04:1
20 605501 1 ZT3400, 21.04:1
21 058776 8 NT .312-18NLG5
22 608241 2 CS .375-16X2.250HXG8
23 712919 2 FW 0.406X1.00X.12 HD ZN
24 600987 1 ZT SPACER TUBE
25 601982 4 CN .250-20X .150 MAX THK
26 605217 2 RESERVOIR, SINGLE FTNG
Not Shown 600767 2 CAP, OVERFLOW TANK
27 768515 4 FW 0.281SAE
28 055939 4 CS .250-20X0.75 HX G5 ZN
29 601001 4 SPRING CLAMP, .75" DIA
30 605218 2 OVERFLOW HOSE, FST
31 120126 2 LINK, TOW VALVE
32 706549 2 HP0.080X1.190
Transmission Assembly & Drive Belt Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:50:51 UTC 2021 4-1
