Comments for Page: 60" Deck
1. Torque to 160 N•m.
2. Torque to 3–7 N•m on these self-tapping screws.
3. Do not torque; the discharge chute must pivot freely.
4. Torque to 4–8 N•m.
5. These blades are approved for use with Catcher 606045:
606253 BLADE, 20.5"-H-F-CW
Item Part No. Qty Name
1 553064 1 SVC, PULLEY COVER RH
2 604324 4 CS .250-20 X .75 HX FLG
3 553065 1 SVC, PULLEY COVER LH
4 602562 2 DECAL, NO SERVICE
5 605469 1 DISCHARGE CHUTE
6 602435 1 SPRING, TORSION
7 086660 1 NT .375-16NLG8
8 605510 1 DECK BELT
9 602432 1 PIN, CHUTE
10 602339 2 CB .50-13 X 4.50 STD ZN
11 604780 2 WHEEL, ANTI-SCALP
12 767962 3 FW .531 x 1.063 x .175
13 781567 5 NT .500-13NLG5
14 113717 2 PULLER W/A 14.53" C/C
15 042630 2 CS .500-13X6.500HXG5
16 602338 1 CB .50-13 X 7.50 STD ZN
17 602344 1 SPACER, ANTI- SCALP 5.73
18 602341 1 WHEEL, ANTI-SCALP
19 605376 1 DECK BUMPER
20 079210 2 FW 0.344X1.0X0.06 ZN
21 604251 2 NT .312-18 HXNL JAM G2ZN
22 016253 2 CB .312-18X .750 FUL ZN
23 606253 3 BLADE, 20.5"-H-F-CW
Not Shown 600901 3 BLADE, F20.50"-L-F-CW
Not Shown 793794 3 BLADE,20.50"-L-F-CW
Not Shown 794214 3 BLADE,20.50"-MUL-F-CW
Not Shown 794230 3 BLADE,20.50"GAT-F-CW
Not Shown 794685 3 BLADE, F20.50"-H-F-CW
24 782474 3 CW .678 X 2.250 X .187
25 781872 3 CS .625-11X1.250HXG5
60" Deck Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:18 UTC 2021 8-14
