1. Torque to 99 N•m.
2. Torque to 41 N•m.
3. Torque to 4–8 N•m.
Item Part No. Qty Name
1 781567 3 NT .500-13NLG5
2 604486 3 FW .531X.812X.089 HD
3 605467 3 DUST SHIELD
4 605512 1 4" IDLER PULLEY
5 607616 1 SPRING, DECK IDLER
6 121052 1 SLED, TENSIONER
7 604790 2 IDLER SLIDE, EXTRUDED
8 604251 7 NT .312-18 HXNL JAM G2ZN
9 604252 6 FW .340X.68X.04 ZN
10 604253 1 CB .50-13 X 2.00 STD ZN
11 705954 3 CS .500-13X1.25 HX G5 ZN
12 798603 3 FW .515X1.65X.12 HD ZN
13 604777 3 SPINDLE SPACER
14 604664 3 PULLEY, DECK DRIVE B-SEC
15 605504 3 SPACER, PULLEY
16 606362 3 DUST SHIELD
17 054502 12 NT .375-16HXG5
18 767954 24 FW 0.379X.82X.06 HD ZN
19 605463 2 6.00" IDLER PULLEY
20 605465 1 BASE, IDLER PULLEY MOUNT
21 017129 1 FW .440X1.00X0.08 ZN
22 605508 1 FW .73X2.25X.31 ZN
23 605380 3 S/C TO 125981
24 005116 12 CS .375-16X1.38 HX G5 ZN
25 016253 7 CB .312-18X .750 FUL ZN
26 604254 2 CB .50-13 X 2.50 STD ZN
54" Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:15 UTC 2021 8-10
