Comments for Page: 48" Rear Discharge Deck
1. Torque to 2.7–6.8 N•m on these self-tapping screws.
2. Torque to 160 N•m.
3. Tighten to 5.4–9.5 N•m to remove play on the cap screw.
Item Part No. Qty Name
1 553531 2 SVC PULLEY COVER,
2 602562 2 DECAL, NO SERVICE
3 604324 4 CS .250-20 X .75 HX FLG
4 605507 1 DECK BELT
5 781567 3 NT .500-13NLG5
6 767962 1 FW .531 x 1.063 x .175
7 042630 2 CS .500-13X6.500HXG5
8 109434 2 PULLER, W/A 10.9" C/C
9 602338 1 CB .50-13 X 7.50 STD ZN
10 602344 1 SPACER, ANTI- SCALP 5.73
11 602341 1 WHEEL, ANTI-SCALP
12 601123 3 BLADE, 16.50"-L-F-CW
Not Shown 601014 3 BLADE, F16.50"-L-F-CW
Not Shown 796623 3 BLADE, 16.50"-MUL-F-CW
Not Shown 796631 3 BLADE, 16.50"-GAT-F-CW
13 782474 3 CW .678 X 2.250 X .187
14 781872 3 CS .625-11X1.250HXG5
48" Rear Discharge Deck Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:13 UTC 2021 8-7
