Comments for Page: 48" Rear Discharge Deck Pulleys & Spindles
1. Torque to 99 N•m.
2. Torque to 41 N•m.
3. Torque to 160 N•m.
4. Torque to 4–8 N•m.
5. 607479 is used on mowers S/N 19124399 & higher.
605463 is used on mowers S/N prior to 19124399.
Item Part No. Qty Name
1 781567 3 NT .500-13NLG5
2 604486 3 FW .531X.812X.089 HD
3 605467 3 DUST SHIELD
4 605512 1 4" IDLER PULLEY
5 124488-4 1 BELT GUIDE
6 607616 1 SPRING, DECK IDLER
7 121052 1 SLED, TENSIONER
8 604251 7 NT .312-18 HXNL JAM G2ZN
9 604252 6 FW .340X.68X.04 ZN
10 604790 2 IDLER SLIDE, EXTRUDED
11 604254 2 CB .50-13 X 2.50 STD ZN
12 781872 3 CS .625-11X1.250HXG5
13 017152 3 FW .688X1.75X.16 HD ZN
14 604661 6 SPACER, SPINDLE PULLEY
15 604665 3 PULLEY, DECK DRIVE B-SEC
16 606362 1 DUST SHIELD
17 054502 12 NT .375-16HXG5
18 767954 24 FW 0.379X.82X.06 HD ZN
19 017129 1 FW .440X1.00X0.08 ZN
20 607479 2 IDLER PULLEY, 5.00"
Not Shown 605463 2 6.00" IDLER PULLEY
21 605508 2 FW .73X2.25X.31 ZN
22 605465 1 BASE, IDLER PULLEY MOUNT
23 783506 3 BLADE SPINDLE ASSEMBLY
24 005116 12 CS .375-16X1.38 HX G5 ZN
25 016253 7 CB .312-18X .750 FUL ZN
26 021980 1 CB .500-13X 3.000 STD Z
48" Rear Discharge Deck Pulleys & Spindles Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:11 UTC 2021 8-5
