Comments for Page: 54" Deck
1. Torque to 3-6 N•m on these self-tapping screws.
2. Do not torque; the discharge chute must pivot freely.
3. Torque to 4-8 N•m.
4. Torque to 160 N•m.
5. These blades are approved for use with Catcher 606045:
606251 BLADE, 18.5"-H-F-CW
601124 BLADE, 18.5"-L-F-CW
797712 BLADE, 18.5"-GAT-F-CW
Item Part No. Qty Name
1 553064 1 SVC, PULLEY COVER RH
2 553065 1 SVC, PULLEY COVER LH
3 604324 4 CS .250-20 X .75 HX FLG
4 602562 2 DECAL, NO SERVICE
5 086660 1 NT .375-16NLG8
6 786483 1 DECK BELT
7 605469 1 DISCHARGE CHUTE
8 602435 1 SPRING, TORSION
9 602432 1 PIN, CHUTE
10 079210 2 FW 0.344X1.0X0.06 ZN
11 604251 2 NT .312-18 HXNL JAM G2ZN
12 605376 1 DECK BUMPER
13 016253 2 CB .312-18X .750 FUL ZN
14 602339 2 CB .50-13 X 4.50 STD ZN
15 604780 2 WHEEL, ANTI-SCALP
16 767962 3 FW .531 x 1.063 x .175
17 781567 5 NT .500-13NLG5
18 602341 1 WHEEL, ANTI-SCALP
19 602344 1 SPACER, ANTI- SCALP 5.73
20 602338 1 CB .50-13 X 7.50 STD ZN
21 113717 2 PULLER W/A 14.53" C/C
22 042630 2 CS .500-13X6.500HXG5
23 606251 3 BLADE, 18.50"-H-F-CW
Not Shown 601012 3 BLADE F18.50"-L-F-CW
Not Shown 601124 3 BLADE, 18.50"-L-F-CW
Not Shown 797704 3 BLADE, 18.50"-MUL-F-CW
Not Shown 797712 3 BLADE, 18.50"-GAT-F-CW
24 782474 3 CW .678 X 2.250 X .187
25 781872 3 CS .625-11X1.250HXG5
54" Deck Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:16 UTC 2021 8-11
