Comments for Page: 48" Side Discharge Deck
1. Torque to 2.7–6.8 N•m on these self-tapping screws.
2. Do not torque; the discharge chute must pivot freely.
3. Torque to 4–8 N•m.
4. Torque to 5–9 N•m.
5. Torque to 160 N•m.
6. These blades are approved for use with Catcher 606045:
606252 BLADE, 16.5"-H-F-CW
601123 BLADE, 16.50"-L-F-CW
796631 BLADE, 16.50"-GAT-F-CW
Item Part No. Qty Name
1 553531 2 SVC PULLEY COVER,
2 602562 2 DECAL, NO SERVICE
3 604324 4 CS .250-20 X .75 HX FLG
4 086660 1 NT .375-16NLG8
5 791335 1 DECK BELT
6 605469 1 DISCHARGE CHUTE
7 602435 1 SPRING, TORSION
8 602432 1 PIN, CHUTE
9 602339 2 CB .50-13 X 4.50 STD ZN
10 604780 2 WHEEL, ANTI-SCALP
11 767962 3 FW .531 x 1.063 x .175
12 781567 5 NT .500-13NLG5
13 042630 2 CS .500-13X6.500HXG5
14 113717 2 PULLER W/A 14.53" C/C
15 602338 1 CB .50-13 X 7.50 STD ZN
16 602344 1 SPACER, ANTI- SCALP 5.73
17 602341 1 WHEEL, ANTI-SCALP
18 016253 2 CB .312-18X .750 FUL ZN
19 605376 1 DECK BUMPER
20 079210 2 FW 0.344X1.0X0.06 ZN
21 604251 2 NT .312-18 HXNL JAM G2ZN
22 606252 3 BLADE, 16.5"-H-F-CW
Not Shown 601014 3 BLADE, F16.50"-L-F-CW
Not Shown 601123 3 BLADE, 16.50"-L-F-CW
Not Shown 796631 3 BLADE, 16.50"-GAT-F-CW
Not Shown 796623 3 BLADE, 16.50"-MUL-F-CW
23 782474 3 CW .678 X 2.250 X .187
24 781872 3 CS .625-11X1.250HXG5
48" Side Discharge Deck Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:10 UTC 2021 8-3
