Comments for Page: Seat - S/N 16123305 & Higher
LENGTHA: 5.0"1. Torque to 9.5 N•m.3. The footrest includes the decal.
Item Part No. Qty Name
1 606474 1 SEAT
2 123688-1 1 HYDRO GUARD, RH
3 036244 8 CS .375-16X1.00 HX G5 ZN
4 767954 8 FW 0.379X.82X.06 HD ZN
5 604324 4 CS .250-20 X .75 HX FLG
6 123689-1 1 HYDRO GUARD, LH
7 601967 1 DECAL, ENGINE COMPART
8 779280 1 DECAL, HOT & HYD OIL
9 605782 1 DECAL, LEVEL FUEL BLOWM
10 553090 1 SEAT PAN CE (WITH DECAL)
11 602562 1 DECAL, NO SERVICE
12 712927 4 FW 0.344X1.00X.12 HD ZN
13 058776 4 NT .312-18NLG5
14 713198 15" SEAL 3/8x3/4 SOLD BY FT
15 601758 2 CN .375-16x.200 MAX THK
16 120802 1 SEAT SUPPORT
17 602407 1 DECAL, HUSTLER ID
18 552856 1 FOOTREST (WITH DECAL)
19 029629 2 CS .375-16X0.75 HXF G5ZN
Seat - S/N 16123305 & Higher Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:21 UTC 2021 9-1
