FUEL & VAPOR LINE LENGTHS
A— FRONT RIGHT SIDE PORT TO TEE (VAPOR)
B— ENGINE TO CROSS (VAPOR)
C— TEE TO CROSS (VAPOR)
D— LEFT BACK PORT TO TEE (VAPOR)
E— FILLER NECK PORT TO TEE (VAPOR)
F— RIGHT BACK PORT TO TEE (VAPOR)
G—29 cm CROSS TO FILTER (VAPOR)
H—5 cm —VALVE TO ENGINE (FUEL)
J—53 cm— TANK TO VALVE (FUEL)
Item Part No. Qty Name
30 016832 1 NT .312-18FLKG5
31 000430 1 WIRE TIE, SMALL/LONG
Fuel System (Multi-Page) Hustler FasTrak SDX CE Parts Manual
Thu Feb 18 06:51:00 UTC 2021 6-3
