6.6.4. How to pack the device
1. Make sure to shut down the device with ‘Packing Mode’.
Refer to “6.6.1. After operation”
2. Lift Packing locks under the bottom and turn them counterclockwise to lock the device (Important).
Move the joystick to check if the device is locked firmly. Device is locked correctly if the device doesn’t move.
3. Screw the user lock lever on the body
Lower the LCD panel as far as possible so that it is at a right angle.
Insert ‘Headrest Foam’ as shown below. The beveled side of the foam faces the headrest.
4. Have the packing box and bottom foam ready.
The wider cut is in the direction of the headrest assy. (The red circle in the photo).
