2.2. How to Set Origin
The steps of setting origin are as follows:
A. Press the ‘LENS’ (Key 1) button.
B. Press the ‘MEASURE’ (Key 2) button.
C. Determine the lens to measure by using two ‘-INDEX’, ’+INDEX’ buttons.
D. ‘D-0.01’ button and ‘D+0.01’ button by the given value in the Standard Lens-set
specification.
E. To save and exit, press the ‘SAVE’ button.
F. Press the ‘EXIT’ button again. And check if the diopter that has been set up in the
basic display screen is shown.
‘SAVE SCREEN INFORMATION’ is as follows:
If you want to return to the previous one without saving in the SAVE screen, press the
rightmost ‘PREV’ button.
CEN: The x, y, coordinates of big center point.
LEN: Average distance between of four points.
CON: The x, y, coordinates of four big points.
DIP: Saving order and the saved diopter.
