Huvitz HLM-7000P Service Manual

Auto Lensmeter HLM-7000P
29
No
Component
Removal method
1
PD BAR PLATE
- First, remove [6] from Back Bone Assembly and separate
[7] [Washer].
- Next, remove 2 screws and separate [20]
- Next, remove 4 screws and take off [17]
- Please see the drawing for disassemble, as needed
- Be careful that there is no scratch and assembly is the
reverse procedure of disassembly.
2
B4_PD-SHAFT
3
PD RACK GEAR SHAFT
4
접시머리 나사 (3*10)
5
Z_WASHER_4X16
6
샘스 SEMS (3*10)
7
도)O RING(PD BAR用)
8
B2UP_PD-SHAFT-BLOCK
9
MACHINE SCREW(FH)
10
B4_ENCODER-SHAFT
11
B2UP_PD-ENCODER-ASSY
12
무두볼트(SS) (3*3)
13
PD BAR CABLE BRK
14
냄비머리 나사 (2*3)
15
PCB ASSY(PD BAR)
16
MACHINE SCREW(TH)
17
PD BAR COVER
18
PD BAR COVER(도장+인쇄)
19
접시머리 탭핑나사 1종 (2*6)
20
B2UP_PD-NOSE-ASSY
