Huvitz HLM-7000P Service Manual

Auto Lensmeter HLM-7000P
33
No
Component
Removal method
1
B4_PEN-FRAME-BRK
- Please see the drawing for disassemble, as needed
- Assembly is the reverse procedure of disassembly.
2
B4_PEN-PRESS-BRK
3
B4_PEN-CONT-SUPPT
4
접시머리 나사 (2.6*6)
5
무두볼트(SS) (3*12) 흑착색(3가 크롬도
금)
6
WRENCH BOLT
7
PEN GUIDE SHAFT
8
PEN GUIDE SPRING
9
E-RING
10
육각 둥근머리 렌치볼트(2*4) 흑착색
(3가크롬도금)
11
평와셔(3*8,0.5T,SUS)
12
B4_PEN-HOLDER-ASSY
13
WRENCH BOLT
14
WASHER(FLAT)
15
PEN-EXTENSION-SPRING
