Huvitz HLM-7000P Service Manual

Auto Lensmeter HLM-7000P
41
No
Component
Removal method
1
B2UP_LCD-FRONT-COVER
- Disconnect all cables from LCD assembly.
- First, remove 4 screws from [12]
- Next, remove 5 screws from [8]
and separate [8] [6] [5] step by step.
- Be careful that there is no scratch and assembly is the
reverse procedure of disassembly.
2
B6_MB-EMI-TAPE
3
B6_LCD-SHIELD-A
4
B6_LCD-SHIELD-B
5
B6_LCD-WINDOW
6
LCD(GRAPHIC)
7
HARNESS
(MB TO LCD_FFC_EMI_Fabric(350mm)
8
B2UP_LCD-PRESS-COVER
9
B6_LCD-SPONGE-GASKET
10
토크힌지(R)
11
토크힌지(L)
12
COVER LCD BACK
13
둥근머리 탭핑나사-2종 (2.6*6)
14
샘스 SEMS (3*8)
15
MACHINE SCREW(TH)
16
SL IMS HUVITZ MARK
