Huvitz HLM-7000P Service Manual

Auto Lensmeter HLM-7000P
43
No
Component
Removal method
1
UV BONE
- Disconnect cables from [5] [8].
- Remove 2 screws from [5] and separate [5] [3].
- Remove 4 screws from [8] and separate [8] [2].
- Be careful that there is no scratch and assembly is the
reverse procedure of disassembly.
2
UV TEFRON(L)
3
UV TEFRON(U)
4
HARNESS(MB TO UV&BLUE LED)
5
PCB ASSY(UVBLUE LED-205)
6
LED(UV 395nm MARUBENI)
7
HARNESS(MB TO UV&BLUE SENSOR)
8
PCB ASSY(UVBLUE SENSOR-200)
9
IC(UV SENSOR) - 변경품
10
냄비머리 나사 (2.6*6)
