Auto Lensmeter HLM-7000P
45
No
Component
Removal method
1
COVER TOP 5
- Disconnect cables from [4].
- Remove 4 screws from [1] and separate [2] [3].
- Be careful that there is no scratch and assembly is the
reverse procedure of disassembly.
2
COVER MEM BUTTON PLATE
3
COVER MEM BUTTON
4
PCB ASSY(HLMM-100)
5
MEM LED DIFFUSION SHEET
6
둥근머리 탭핑나사-2종(2*6,니켈)
